Enhance vacuum glazing
LandVac Enhance Vacuum Glazing:

Where Tradition Meets Tomorrow.

A long-term, historically sympathetic solution for reglazing existing windows and doors in conservation applications.

Find Out More

Innovative Glass for Heritage Windows

For many years, the choice when reglazing historic windows has been poor performing single glazing, or unreliable and non-traditional slim double glazing, but not any more.

Get a Quote
LandVac heritage Vacuum Glazing Cross Section
Looks like Single Glazing - Performs like Triple Glazing

Advantages of LandVac Enhance Glazing for Historic Window Renovation

LandVac Enhance glazing offers a range of benefits for listed projects and buildings located in conservation areas. With its innovative design and advanced features, it overcomes the limitations of standard double glazing and provides a superior solution. Eliminating double reflection (addressing planning permission concerns), LandVac Enhance glazing stands out as a reliable and energy-efficient choice. Let's explore the advantages it brings to the table:

  • LandVac Enhance glazing is an ideal solution for heritage projects and buildings in conservation areas.
  • It eliminates the double reflection issue associated with standard double glazing.
  • It has no evacuation plug and a linear getter located close to the unit perimiter.
  • LandVac Enhance glazing is easier to install and maintain compared to slim double glazing.
  • The glazing offers superior insulation properties, leading to significant energy savings.
  • It also contributes to a reduction in carbon emissions.
  • LandVac Enhance is always toughened as standard, so there's no need to apply unsightly films.
  • It allows property owners to enhance the energy efficiency of their buildings without compromising their heritage or aesthetics.
  • Acoustic performance of 39dB, vastly better than anything else on the market.
LandVac Enhance heritage vacuum glass
Perfect for Heritage Restoration Projects and Conservation Areas

VACUUM GLASS vs TRADITIONAL GLASS

Compared to Slim Double Glazing, LandVac Enhance has:

  • Higher energy efficiency
  • Noise reduction
  • Better light transmission
  • Slimmer profile
  • Longer service life

Single Glazing

Single Glazing vs Heritage Vacuum Glazing

Slim Double Glazing

Slim Double Glazing vs Heritage Vacuum Glazing

LandVac Enhance

LandVac Heritage Double Glazing image
Single Glazing Slim Double Glazing LandVac Enhance
Overall Thickness 4mm 11 - 16mm 8.3mm
U-Value 5.8 1.2 - 1.9 0.4
Acoustic Reduction (RW) 25dB 31dB 39dB
Estimated Lifespan 25+ years 1 - 10 years 25+ years

Data Table

Download a PDF of this data

Download

Standard Low E Coating (S1.10)

Configuration U-Value (W/m²K) Visible Light Transmittance SHGC (g-value) Weighted Sound Reduction Index
4TL+0.3V+4T 0.4 76% 0.58 36dB
5TL+0.3V+5T 0.4 75% 0.58 37dB
6TL+0.3V+6T 0.4 74% 0.58 39dB

Premium Low E Coating (D80)

Configuration U-Value (W/m²K) Visible Light Transmittance SHGC (g-value) Weighted Sound Reduction Index
4TL+0.3V+4T 0.4 70% 0.40 36dB
5TL+0.3V+5T 0.4 69% 0.39 37dB
6TL+0.3V+6T 0.4 68% 0.39 39dB

Solar Control Coating (XDTB0159)

Configuration U-Value (W/m²K) Visible Light Transmittance SHGC (g-value) Weighted Sound Reduction Index
4TL+0.3V+4T 0.4 53% 0.33 36dB

Ultraclear Unit (S1.10)

Configuration U-Value (W/m²K) Visible Light Transmittance SHGC (g-value) Weighted Sound Reduction Index
4TL+0.3V+4TUC 0.4 83% 0.68 36dB
Speed up your project development - specify LandVac on NBS Source

Shapes

LandVac Enhance is available in a wide variety of shapes. Here are just a few examples to inspire your project:

LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape
LandVac Vacuum Glazing profile shape

Width to Height maximum ratio 1:6 for 8.3mm. Bigger than that and it will be 10.3mm
CAD drawings must be supplied for any shape orders.
General Criteria and Specification Notes
Maximum Unit Size 1450mm x 2480mm
Minimum Unit Size 190mm x 230mm.
All LandVac Glass is toughened and has been certified to BS12150-1.
U-value certified using hot box testing at IFT Rosenheim on 9.3 unit.

LandVac Enhance Glazing: The Clear Choice Reglazing in Heritage and Conservation Projects

LandVac Enhance glazing is an ideal solution for heritage projects and buildings located in conservation areas as it eliminates the double reflection that makes standard double glazing unsuitable. This feature also addresses planning permission issues that arise from this visual disturbance.

The unit has low sightlines and no evacuation plugs, so it fits neatly into most existing rebates with minimal work.

Compared to slim double glazing, LandVac Enhance heritage glazing is significantly thinner, making it easier to install without deepening rebates. It also comes with a 15 year warranty and an expected service life far beyond that, completely the opposite of the high maintenance and replacement requirements of slim double glazing.

Additionally, its insulating properties are far superior, resulting in significant energy savings and a reduction in carbon emissions. This makes it an excellent choice for both new construction and retrofitting projects, allowing property owners to enhance the energy efficiency of their buildings without compromising their heritage or aesthetics.

Templeton House
Vacuum glazing in a heritage style window
Vacuum glazing installed in herigate windows
Georgian sash windows
