Certified 0.34 W/m²K Centre-Pane U-Value for LandVac Glazing
Why does a 0.34 W/m²K centre-pane U-value matter? A centre-pane U-value of 0.34 W/m²K allows less than half the heat […]
Why does a 0.34 W/m²K centre-pane U-value matter?
A centre-pane U-value of 0.34 W/m²K allows less than half the heat loss of high-spec triple glazing. Designers gain lower energy demand and a simpler route to 2025 Part L compliance. Because the figure measures the glass alone (without the frame), it represents the unit’s maximum insulation.
Who certified the result?
The value is verified by ift Rosenheim, an independent German institute that has tested windows, façades and glass since 1966.
- Accreditation – ISO 17025 laboratory and EU notified body 0757.
- Standards expertise – contributor to EN 1279, EN 14351-1 and ISO thermal methods.
- Scope – more than 5 000 accredited tests each year covering thermal, structural and security performance.
- UK recognition – Building Control departments and BRE accept ift Rosenheim certificates, so specifiers can quote the data without extra checks.
ift Rosenheim used the ISO 19916-1 guarded hot-plate method, testing a 500 mm × 500 mm LandVac specimen and confirming the centre-pane U-value of 0.34 W/m²K.
To view the full certificate, simply contact us and we will email the report.
What exactly was tested?
| Property | Value |
|---|---|
| Unit size | 500 mm × 500 mm |
| Edge thickness | 8.2 mm |
| Mass | 4.9 kg |
| Test temperatures | 17.5 °C (warm) / 2.5 °C (cold) |
| Heat flow (Φ) | 0.3 W |
| Thermal resistance (R) | 3.00 m²·K/W |
| Centre-pane U-value | 0.34 W/m²K |
How does 0.34 W/m²K compare with other slim glass available in Britain?
| Product | Technology | Centre-pane U-value | Typical thickness | UK availability |
|---|---|---|---|---|
| LandVac | Vacuum | 0.34 | 8.3 mm | Distributed through Vacuum Glazing UK |
| Fineo 8 | Vacuum | 0.70 W/m²K | 7.7 mm | Distributed via Fineo partner network |
| HaanGlas VIG | Vacuum | 0.58 W/m²K | 8 mm | Via specialist installers (e.g. Scott James Windows) |
| Panasonic Glavenir | Vacuum | 0.58 W/m²K | 8.1 mm | Limited import / special order |
| Histoglass HD13 | Slim krypton double | 1.30 W/m²K | 13 mm | Direct from Histoglass UK |
| Heritage Glass UK | Slim krypton double | 1.50 W/m²K | ≈ 12 mm | Supplied by Heritage Glass UK |
All values are centre-pane figures. Whole-window performance rises once frames and spacers are included.
Why is LandVac so efficient?
(Manufacturer data – not part of the ift certificate)
- Ultra-high vacuum (≤ 0.1 Pa) removes conduction and convection.
- Dual-silver low-E coating reflects radiant heat indoors.
- Micro-pillars 0.5 mm wide, spaced about 55 mm apart, support the cavity yet remain almost invisible.
- Lead-free flexible edge seal, durability-tested for 25 years.
These features achieve top-tier insulation in an 8.3 mm unit.
Project benefits
- Meets or exceeds 2025 Part L window targets when paired with an efficient frame.
- Slim 8 mm profile fits heritage rebates and minimalist aluminium systems.
- Weight similar to modern double glazing, easing sensitive retrofits.
- Warmer interior glass surface reduces condensation on cold mornings.
Frequently asked questions
Is 0.34 W/m²K a whole-window U-value?
No. It measures the glass only. Frames and spacers raise the overall value, although larger panes still benefit because edges make up a smaller share of their area.
Can LandVac replace single glazing without altering heritage frames?
In most cases yes, provided the rebate depth is at least 8 mm. We supply section drawings and whole-window calculations on request.
How can I access the full ift Rosenheim report?
Please contact us and we will send the certificate, test tables and any additional technical data you need.
Ready to specify verified 0.34 W/m²K glazing?
Contact us to request the certificate, project-specific thermal models or a detailed quotation. Our technical team will confirm compatibility, lead times and installation guidance within one working day.
